Permanent Overband Magnetic Separator
Permanent overband magnetic separator is an iron separator suspended above the conveyor belt, with a built-in high-performance permanent magnet system, a reduction motor and an iron unloading belt. The magnetic iron separator can sustainably absorb ferromagnetic impurities to achieve the purpose of iron removal and protection of downstream equipment.
Product Features
1. A permanent magnet generates a magnetic field with a sophisticated dual-pole structure, resulting in deep magnetic penetration, high magnetic field strength, and strong suction.
2. Low energy consumption, no operating energy consumption, no overheating, energy-saving and environmentally friendly, ensuring trouble-free, long-term operation in harsh environments.
3. Automatic iron unloading design eliminates downtime during unloading, making it suitable for automated production lines, eliminating manual cleaning and improving production efficiency.
4. Flexible installation: Permanent overband magnetic separator can be installed horizontally or tilted, compatible with belt conveyors, vibrating feeders, and other equipment.
Product Technical Parameters
We can customize the permanent overband magnetic separator based on your technical parameters such as bandwidth, rated lifting height, magnetic field strength, material thickness, etc. At the same time, you can choose permanent magnet magnetic separator or electromagnetic magnetic separator.
|
Model |
Adaptive bandwidth (≤mm) |
Suspension height |
Magnetic field intensity(≥mT) |
Material thickness |
Excitation power |
Adaptive band velocity |
Weight |
|
RCYD(C)-5 |
500 |
150 |
63 |
80 |
1.5 |
2.5 |
750 |
|
RCYD(C)-6 |
600 |
175 |
63 |
120 |
1.5 |
920 |
|
|
RCYD(C)-6.5 |
650 |
200 |
63 |
150 |
1.5 |
1200 |
|
|
RCYD(C)-8 |
800 |
250 |
63 |
200 |
2.2 |
1400 |
|
|
RCYD(C)-10 |
1000 |
300 |
65 |
250 |
3 |
2120 |
|
|
RCYD(C)-12 |
1200 |
350 |
65 |
300 |
4 |
3350 |
|
|
RCYD(C)-14 |
1400 |
400 |
68 |
350 |
4 |
4450 |
|
|
RCYD(C)-16 |
1600 |
450 |
68 |
400 |
5.5 |
6200 |
|
|
RCYD(C)-18 |
1800 |
500 |
71 |
450 |
5.5 |
8100 |
|
|
RCYD(C)-20 |
2000 |
550 |
71 |
500 |
7.5 |
9700 |
|
Model |
Outline size(mm) |
|||
|
A |
B |
C |
D |
|
|
RCYD(C)-5 |
1900 |
735 |
935 |
950 |
|
RCYD(C)-6 |
2050 |
780 |
1030 |
1100 |
|
RCYD(C)-6.5 |
2165 |
780 |
1080 |
1200 |
|
RCYD(C)-8 |
2350 |
796 |
1280 |
1300 |
|
RCYD(C)-10 |
2660 |
1010 |
1720 |
1550 |
|
RCYD(C)-12 |
3225 |
1050 |
1980 |
1800 |
|
RCYD(C)-14 |
3350 |
1180 |
2160 |
1950 |
|
RCYD(C)-16 |
3580 |
1210 |
2450 |
2200 |
|
RCYD(C)-18 |
3580 |
1210 |
2450 |
2200 |
|
RCYD(C)-20 |
3800 |
1300 |
2700 |
2400 |
Product drawings and dimensions
Product Application
1. Mining and metallurgical industry: ore crushing and beneficiation, coal processing
2. Power industry: coal-fired power plants, hydropower stations
3. Chemical and glass industry: chemical raw material processing, glass manufacturing
4. Food industry: Removing iron filings from raw materials such as flour and grains
5. Environmental recycling industry: garbage disposal, scrap metal recycling
Product Certificate
In May 2025, an electromagnetic iron remover with an automatic cleaning structure.
In August 2022, a suspended permanent magnet iron remover with built-in collection function.
In 2023, obtain ISO9001:2015 quality management system certification.
In 2022, obtain high-tech enterprise certificate.
Company Profile
Shandong Linqu Sanxing Electromagnetism Equipment Co.,Ltd., established in 2008 and covering an area of 10,000 square meters, is an equipment manufacturing company integrating research, design, production, installation, and commissioning. The company has obtained ISO 9001,High-Tech Enterprise, Quality Management System Certification, GB/T19001-2016/ISO9001:2015 Environmental Management System Certification, and GB/T24001-2016/ISO14001:2015 Occupational Health and Safety Management System Certification, guaranteeing the quality of our products and after-sales service. Currently, our comprehensive production capacity and various economic indicators rank among the best in the domestic industry. Our leading products include electromagnetic separators, permanent magnetic separators, magnetic separators, dry separators, metal detectors, lifting electromagnets, screw weighers, screw conveyors, and high-frequency vibrating screens. We export our products to numerous countries and regions, including Russia, Australia, Germany, Brazil, India, and South Africa.
