High Frequency Electromagnetic Vibrating Screen

Product Details

The high-frequency electromagnetic vibrating screen is a new type of screening machinery with vibrating screen surface. The high-frequency electromagnetic vibrating screen directly vibrates the screen surface through the vibration system while the frame remains stationary. The vibration system operates in a resonant state. This design features low energy consumption, no dynamic load, and easy maintenance. The amplitude of the screen surface is controlled by several groups of vibration systems separately, Can be adjusted in segments at any time. The screen is composed of a separately tensioned composite screen and a supporting net, which have strong self-cleaning ability and are easy to replace.

Working principle

It is mainly applied in iron ore, coal washing and chemical industries, used for wet separation of strong magnetic minerals with a particle size of 6-0 millimeters, and the minerals are divided into two products: magnetic substances and non-magnetic substances.

This machine is mainly used in iron ore for screening the bottom materials for grinding and dehydration. The dehydration effect is remarkable, increasing the concentration of the second grinding, reducing the buoyancy of the second grinding, increasing fineness, improving output, preventing the second grinding from flow backwards, improving the working environment, and it can also be used for dehydration before the filter press to make the filter cake better.

Technical characteristics

1. The computer control box adopts advanced technologies such as large-scale integrated circuits, bidirectional silicon controlled, and maintenance-free features. It is centrally controlled by the single-chip microcomputer and simultaneously controls multiple silicon controlled. It adopts a low-energy consumption design scheme. The computer control box achieves nearly zero power consumption, ensuring that the overall electrical performance is not affected by environmental and temperature changes. The time interval can be adjusted at will. It has a high-speed instantaneous strong vibration function, which can automatically clean the material on the screen and solve the problem of clogged screens. The screening rate is greatly improved, and the economic benefits are significant.

2. The fully sealed design is achieved through the use of a sealed structure. By eliminating the previous slurry receiving chute on the screen, the occurrence of leakage, spillage, and evaporation of slurry on the screen is reduced, significantly improving the working environment for workers and greatly reducing their labor intensity.
